SF15DC
2-WAY SELF POWERED LOUDSPEAKER SYSTEM
2-WAY loudspeaker system provides high output, low distortion sound reinforcement for the entire range of pro audio applications.
| Speaker Power Capability • LF 750W (EIAJ) - 4 Ohms • LF 1500W (PEAK) - 4 Ohms • HF 200 W (EIAJ) - 16 Ohms • HF 740 W (PEAK) - 16 Ohms |
Coverage • Horizontal 40° • Vertical 60° |
Sensitivity (dB 1 Watt @ 1 m) • LF active 99dB - 128 dB Max SPL (EIAJ) calc. • LF active 99dB - 131 dB Max SPL (PEAK) calc. • HF active 106dB - 129 dB Max SPL (EIAJ) calc. • HF active 106dB - 135 dB Max SPL (PEAK) calc. |
The 380 mm (15”) low frequency cone with 75 mm (3”) voice coil with Neodymium magnet and 75 mm (3”) voice coil high frequency compression driver provides higher output and low distortion plus enhanced power handling capabilities for better performance in both touring and permanently installed applications. SF15DC is ideal for better performance in both touring and permanently installed applications. The digital amplifier with DSP controller allows the pilotage in Bi-Amp mode of the speakers.
APPLICATION
LSS's SF15DC is a loudspeaker designed as main speaker in live events, as monitor system, front or delay fill. SF15DC can be used stand alone or with one or more other loudspeaker to create horizonta array.
- 15" LF in Vented Enclosure
- 1.4" Titanium Driver (3" VC) on Constant Directivity Rotable Horn
- Powering Mode: Bi-Amp with Digital Amplifier, DSP Controller
- Included Hardware for Easy and Quick Installation
- For Touring or Permanent Installation
PHYSICAL
Dimensions mm (±1 mm)
• Height 810
• Front Width 485
• Rear Width 235
• Depth 575
• Trapedoidal angle (degrees) 13° side
Peso in Kilogrammi
• Net weight 38
• Shipping weight 41
• System configuration 2-way full range
Enclosure Material
• Enclosure Material: Birch Plywood of 18 mm
• Finish: Texture Polyurethane Black Paint
• Suspension: Custom 4 Point Mounting Suspension
• Grille: Powder Coated Perforated Steel with anti-dust foam
• Connectors: Neutrik Powercon + XLR
• Optional Accessories: Fly Clip with Ring,Flight Case, Bumper, Hardware Array
• Height 810
• Front Width 485
• Rear Width 235
• Depth 575
• Trapedoidal angle (degrees) 13° side
Peso in Kilogrammi
• Net weight 38
• Shipping weight 41
• System configuration 2-way full range
Enclosure Material
• Enclosure Material: Birch Plywood of 18 mm
• Finish: Texture Polyurethane Black Paint
• Suspension: Custom 4 Point Mounting Suspension
• Grille: Powder Coated Perforated Steel with anti-dust foam
• Connectors: Neutrik Powercon + XLR
• Optional Accessories: Fly Clip with Ring,Flight Case, Bumper, Hardware Array
PERFORMANCE
Frequency Response
• ±5 dB 50Hz to 18Kz
• -10 dB 40Hz
Sensitivity (dB 1 W @ 1 m)
• LF 99dB
• HF 106dB
Max SPL Calculated
• LF 128 dB
• HF 129 dB
Nominal Impedance (Ohms)
• LF 4
• HF 16
Power Handling (Watts EIAJ)
• Bi-Amp 750 + 200
• LF 750
• HF 200
Nominal Dispersion (degrees @ - 6 dB)
• Horizontal 40°
• Vertical 60°
ADDITIONAL DATA
Product Series SF
• LF Subsystem & Loading One 380 mm (15") Neodymium woofer vented
• HF Subsystem & Loading One 75 mm (3") driver /75mm (3")voice coil Neodymium compression driver
• Powering Mode: Bi-Amp with Digital Amplifier, DSP Controller
• ±5 dB 50Hz to 18Kz
• -10 dB 40Hz
Sensitivity (dB 1 W @ 1 m)
• LF 99dB
• HF 106dB
Max SPL Calculated
• LF 128 dB
• HF 129 dB
Nominal Impedance (Ohms)
• LF 4
• HF 16
Power Handling (Watts EIAJ)
• Bi-Amp 750 + 200
• LF 750
• HF 200
Nominal Dispersion (degrees @ - 6 dB)
• Horizontal 40°
• Vertical 60°
ADDITIONAL DATA
Product Series SF
• LF Subsystem & Loading One 380 mm (15") Neodymium woofer vented
• HF Subsystem & Loading One 75 mm (3") driver /75mm (3")voice coil Neodymium compression driver
• Powering Mode: Bi-Amp with Digital Amplifier, DSP Controller
